Wafer Lift Check Valve

Name: Wafer Lift Check Valve | ZEMTECH GAS
SKU: H71H

SKU H71H Category Check Valves Tags Automatic Check Valve, Check Valve, Compact Check Valve, H71H, Industrial Check Valve, Lift Check Valve, Non Return Valve, Wafer Check Valve, Wafer Lift Check Valve

H71H wafer lift check valve provides automatic non-return protection in a compact, lightweight design for steam, water, oil, and compatible industrial pipeline systems. Its ultra-thin wafer body and guided lift-disc structure make it suitable for pump discharge lines, HVAC systems, compact skids, and space-limited installations.

PRODUCT DETAILS

The H71H Wafer Lift Check Valve is designed to provide automatic non-return protection in steam, water, oil, and compatible industrial pipeline systems.

Its ultra-thin wafer body is installed between pipeline flanges using through-bolts, providing a much shorter face-to-face dimension and lower overall weight compared with conventional flanged check valves. This makes it especially suitable for compact piping systems, skids, retrofits, and installations where space and weight are important.

The valve operates automatically without an external actuator. Forward flow lifts the guided disc away from the seat, while reverse flow or pressure loss causes the disc to return to the seat and prevent backflow. A spring-loaded configuration can also be supplied where faster closing or vertical installation is required.

Technical Specifications

Valve Type	Wafer Lift Check Valve
Connection	Wafer / Between Flanges
Size Range	DN15-DN400
Pressure Rating	PN16 / PN25 / PN40 / PN64, ASME Class 150 / 300
Body Material	Ductile Iron, WCB Carbon Steel, CF8, CF8M
Sealing Surface	Cr13 Stainless Steel, Stellite Option
Disc / Guide Material	Cr13 Stainless Steel, SS304, SS316
Operation	Automatic Non-Return
Installation	Horizontal Pipeline; Spring-Loaded Option for Vertical Installation
Typical Applications	Steam, Water, Oil, Pump Discharge, HVAC, Compact Skids and Industrial Pipelines

Key Features

Ultra-thin wafer body for space-saving installation
Lightweight design compared with conventional flanged check valves
Automatic non-return operation without external actuator
Guided lift-disc design for stable and reliable closing
Short closing stroke for quick response to reverse flow
Cr13 metal sealing surface for wear resistance
Spring-loaded option available for vertical installation
Suitable for compact skids, HVAC, pump systems, and industrial pipelines

Applications

The H71H Wafer Lift Check Valve is suitable for pump discharge lines, compressor systems, steam pipelines, boiler feedwater and condensate systems, oil pipelines, HVAC chilled and heating water systems, compact skids, retrofits, risers, and other industrial applications requiring reliable reverse-flow protection with limited installation space.

ZEMTECH GAS provides product selection support based on valve size, pressure rating, body material, mating flange standard, service medium, operating temperature, installation orientation, sealing surface, and spring-loaded requirements.

TECHNICAL SPECIFICATIONS

Product Specifications

Specifications may vary by model, material, pressure rating and project requirements.

Model	H71H
Size Range	DN15-DN400
Pressure Rating	PN16 / PN25 / PN40 / PN64, Class 150 / 300
Body Material	Ductile Iron, WCB, CF8, CF8M
Installation	Horizontal, Spring-Loaded Vertical Option

Quality Control

Products are checked according to order requirements and applicable specifications before delivery

Technical Documentation

Product specifications, technical data, and related documents can be provided based on project requirements

Selection Support

Our team can assist with product selection based on application, medium, pressure, size, and installation requirements
